Austech Flexible Wire Single Insulated 1 Core 4mm 0.6/1kV Stranded Tinned Copper V90HT PVC Orange
Loading...
Description
Flexible Wire, Single Insulated, 1 Core, 4 mm, Stranded Tinned Copper, 0.6/1 kV, 26 Amp, 56/0.3 mm Strands, 4.7 mm Overall Diameter, 1 mm Insulation Thickness, Insulation Resistance: 5.09 MOhm/m, V-90HT PVC Insulation, Unsheathed, Orange Insulation
Key Specifications
| SKU |
CAB10057
|
|---|---|
| Brand |
Cables Plus
|
| Product Type |
Flexible Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 10057 |
| Conductor Size | 4 mm |
| Conductor Type | Stranded Tinned Copper |
| Current | 26 Amp |
| Insulation Colour | Orange |
| Insulation Material | V-90HT PVC |
| Insulation Resistance | 5.09 MOhm/m |
| Insulation Thickness | 1 mm |
| Overall Diameter | 4.7 mm |
| Number of Cores | 1 Core |
| Sheath Material | Unsheathed |
| Stranding | 56/0.3 mm |
| Voltage | 0.6-1 kV |
