Aflex Heavy Duty Flexible Cable 2 Core & Earth 10mm 0.6/1kV Annealed Copper NBR/NBR
Loading...
Description
Flexible Cable, Heavy Duty, 2 Core & Earth, 10 mm, Stranded Annealed Copper, 0.6/1 kV, 318/0.21 mm Strands, 23.7 mm Overall Diameter, NBR Insulation, NBR Sheath, Brown Blue Green/Yellow Cores
Key Specifications
| SKU |
AFLHD03/10B
|
|---|---|
| Brand |
Aflex
|
| Product Type |
Flexible Cable Heavy Duty
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | EA |
| Vendor Product | HD03/10B |
| Conductor Size | 10 mm |
| Conductor Type | Stranded Annealed Copper |
| Core Colours | Brown/Blue/Green/Yellow |
| Insulation Material | Nitril Modified PVC (NBR) |
| Number of Cores | 2 Core + Earth |
| Overall Diameter | 23.7 mm |
| Sheath Material | Nitril Modified PVC (NBR) |
| Stranding | 318/0.21 mm |
| Voltage | 0.6-1 kV |
